Performance and characteristics of Q11 series mechanical plate shears:
The Q11 series mechanical up drive plate shears adopt single side open drive, the main shaft is the crankshaft, the frame is a casting piece, the appearance is beautiful and generous, the structure is compact and solid, the operation is simple and easy, and the work is safe and reliable.
It is widely used for cutting of motors, electrical appliances, vehicle maintenance, sheet metal processing, hardware manufacturing and all other metal plates.
Technical parameters of Q11 mechanical plate shears:
Product specifications | External dimensions(mm) | Scissorable board thickness(mm) | Scissorable board width(mm) | Number of cuts | shear angle | Workbench height(mm) | Rear blocking distance(mm) | power(kw) | weight(T) |
3×1300 | 2115×1500×1300 | 3 | 1300 | 58 | 2.25 | 800 | 350 | 3 | 1.1 |
3×1500 | 2515×1500×1300 | 3 | 1500 | 58 | 2.25 | 800 | 350 | 3 | 1.3 |
4×2000 | 3200×1500×1600 | 4 | 2000 | 54 | 1.30 | 800 | 500 | 5.5 | 3 |
6.3×2000 | 3180×1765×1500 | 6.3 | 2000 | 40 | 2 | 800 | 500 | 7.5 | 4.3 |
8×2000 | 3180×1765×1550 | 8 | 2000 | 40 | 2 | 800 | 500 | 11 | 4.8 |
4×2500 | 3580×1500×1600 | 4 | 2500 | 54 | 1.30 | 800 | 500 | 5.5 | 3.5 |
6×2500 | 3675×2200×2020 | 6 | 2500 | 40 | 2 | 850 | 500 | 7.5 | 5 |
8×2500 | 3675×2250×2450 | 8 | 2500 | 40 | 2.30 | 850 | 500 | 11 | 5.5 |
13×2500 | 3680×2330×2500 | 13 | 2500 | 30 | 3 | 900 | 500 | 15 | 11 |
16×2500 | 3880×2800×2450 | 16 | 2500 | 30 | 3 | 900 | 500 | 22 | 13 |
20×2500 | 3950×2800×2900 | 20 | 2500 | 25 | 3 | 900 | 500 | 22 | 18.5 |
25×2500 | 4050×2850×2900 | 25 | 2500 | 22 | 3 | 900 | 500 | 37 | 22 |
Note: If the parameters in this table are inconsistent with the machine tool data, the actual data of the machine tool shall prevail. The Company reserves the right of final interpretation.
